[Cytiva] 단백질 전기영동장치 구성품 안내











SE250	SE260
[SE250-10A-.75]	[SE260-10A-.75]
·  Lower Buffer Chamber                 ·  Upper Buffer Chamber/Cooling Core                 ·  Safety Lid with High Voltage Leads                 ·  Casting Cradle w/Sealing Gasket Set                 ·  Casting Clamp Assemblies, 2 pcs                 ·  Cams, 4 pcs                 ·  Glass Plates, Rectangular, 10 x 8 cm, 10 pcs                 ·  Alumina Plates, Notched, 10 x 8 cm, 2 pcs                 ·  Spring Clamps, 4 pcs                 ·  Combs, 10 well, 0.75mm thick, 2 pcs                 ·  T-Spacers, 0.75mm thick, 4 pcs                 ·  Well Locating Decals, 2 pcs                 ·  Gel Seal	·  Lower Buffer Chamber                                    ·  Upper Buffer Chamber/Cooling Core                                    ·  Safety Lid with High Voltage Leads                                    ·  Casting Cradle w/Sealing Gasket Set                                    ·  Casting Clamp Assemblies, 2 pcs                                    ·  Cams, 4 pcs                                    ·  Glass Plates, Rectangular, 10 x 10.5 cm, 10 pcs                                    ·  Alumina Plates, Notched, 10 x 10.5 cm, 5 pcs                                    ·  Spring Clamps, 4 pcs                                    ·  Combs, 10 well, 0.75mm thick, 2 pcs                                    ·  T-Spacers, 0.75mm thick, 4 pcs                                    ·  Well Locating Decals, 2 pcs                                    ·  Gel Seal

                      * 상기 제품들은 다른 구성품으로 교체 불가합니다.



[EPS 301 Power Supply]

사 진
품 번	18113001
품 명	EPS 301 Power Supply (SE250/SE260 전기영동장치와 호환)



[SE250, SE260 Electrophoresis Systems]

사 진
품 번	SE252-GLSS	SE208-GLSS	SE254B-GLSS
품 명	Spring Clamps	Foam Gasket	Upper Buffer Chamber Cooling Core (Foam Gasket 포함)



[Dual Gel Caster]

사 진
품 번	SE245-GLSS	SE6005L-GLSS	SE249-GLSS	SE6003U-2-GLSS
품 명	Dual Gel Caster	Cams –4 ea/pk	Casting Clamp Assembly -1 each (Thumbscrews 6ea 포함)	Thumbscrews -12 ea/pk



[Other Accessories (MiniVE^TM, SE260, SE250)]

사 진	품 번	품 명
	SE2119T-2-XX-GLSS	T-Spacers, 8 cm Length, 0.75/1.0/1.5 mm Width, 2/pk (두께 별로 마지막 코드 상이)
	SE2619T-2-XX-GLSS	T-Spacers, 10.5 cm Length, 0.75/1.0/1.5 mm Width, 2/pk (두께 별로 마지막 코드 상이)
	SE202GN-5-GLSS	Notched Glass Plates, 10 x 8 cm, 5 pcs
	SE262GN-5-GLSS	Notched Glass Plates, 10 x 10.5 cm, 5 pcs
	SE202P-10-GLSS	Rectangular Glass Plates 10 x 8 cm, 10 pcs
	SE262P-5-GLSS	Rectangular Glass Plates 10 x 10.5 cm, 5 pcs
	SE202N-GLSS	Notched Alumina Plate, 10 x 8 cm
	SE202N-10-GLSS	Notched Alumina Plates, 10 x 8 cm, 10 pcs
	SE262N-5-GLSS	Notched Alumina Plates,10 x 10.5 cm, 5 pcs
	SE211A-X–XX-GLSS	Combs [X: Well 수(10 or 15 well), XX: Comb의 두께]
